Aluminium wires in india || Ravi Pipes and Wires

At Ravi pipes and wires, we manufacture aluminium wires that are a perfect combo of quality, strength and performance. Every wire is designed in such a way that it proves to be a reliable and long-lasting solution for every industry. RAVI has become a trusted name for those who use aluminium wires for modern wiring. Be it a commercial or industrial application, our aluminium wires are best-fit for every project. Quality, innovation and consistency—you get these three things with RAVI's aluminium wires, without any compromise.

Aluminium Wires

Available Sizes :

Available Categories :

Available Colours :

Key Features & Benefits:

High Conductivity

Ravi pipes and wires are made of pure copper which makes electricity transmission more efficient and reliable. Power loss is very less, due to which electricity bill also remains under control.

Excellent Flexibility

Their multistrand construction makes them flexible. The wire can be easily routed even around tight corners or complex bends.

Flame Retardant

During a fire accident, normal PVC wires emit toxic and black smoke which impacts both visibility and safety. But RAVI FRLS Wires are specially made with flame retardant properties which take fire safety to the next level.

Durable Installation

The installation process is quick and easy, which is very convenient for electricians. These have been designed for perfect fitting with Ravi conduit.

Superior Insulation

Ravi pipes and wires FRLS wires feature high-quality sheath insulation that handles wear & tear, chemical exposure, and rough usage easily.

Wide Range of Sizes & Colours

Different gauge sizes and multiple colour options are available, making circuit identification easy and covering every requirement.

Cost-Effective

With long-term performance, their pricing is also practical. An affordable and dependable choice for surface wiring.

Compliance & Standards

These wires comply with all the norms of IS 694:1990 (Indian Standard for Rigid Non-Metallic Conduits).

Materials

1. Conductor: The core part of our wires is made from high-purity electrical-grade aluminium, which ensures excellent conductivity and mechanical strength. This aluminium is both lightweight and strong, so it is perfect for industrial and commercial wiring.

2.Insulation: These wires use high-quality Polyvinyl Chloride (PVC) compound which is top class in electrical and mechanical properties. It has built-in flame retardancy, which protects the wire from heat and short-circuit damage and ensures long-term durability.

Nominal Area of Conductor	Nos & Diameter of Wire		Nominal Thickness of Insulation	Thickness of Sheath (Nominal)	Overall Diameter (Approx.)	Current Rating AC	Max. Resistance of Conductor at 20°C
Nominal Area of Conductor	Solid	Stranded	Nominal Thickness of Insulation	Thickness of Sheath (Nominal)	Overall Diameter (Approx.)	Current Rating AC	Max. Resistance of Conductor at 20°C
Sq.mm	mm	mm	mm	mm	mm	mm	mm
2.5	1/1.82	7/0.65	0.70	1.0	10.5x6.6	18	12.10
4	1/2.26	7/0.86	0.80	1.0	12.0x7.4	23	7.41
6	1/2.79	7/1.05	0.80	1.1	13.0x8.0	30	4.61
10	1/3.57	7/1.35	1	1.4	16.0x9.6	40	3.08

APPLICATION OF MULTI-STRAND WIRES

• Electrical Wiring: Multi-strand wires are used in residential, commercial, and industrial electrical systems where flexibility and reliable current flow are required.

• Power Transmission & Distribution: These wires are very popular in overhead lines and power distribution networks due to their high conductivity and lightweight.

• Automotive Industry: Multi-strand wires are used in vehicles' wiring harnesses and battery cable systems for strong connections and vibration resistance.

• Telecommunications: Multi-strand wires are also used in some special communications cables where flexibility and consistent signal delivery are required.

• Manufacturing: These wires are essential for the winding purposes of transformers, motors and other electrical equipment due to their excellent electrical properties.

• Construction: Multi-strand wires are used in construction and structural setups where lightweight wiring with strength is required.

Why Choose "Ravi pipes and wires" Aluminium Wires?

• Uncompromising Quality: We never compromise on quality. Every wire coil is passed through strict testing that follows top-level industry standards.

• Advanced Manufacturing: Our manufacturing unit uses cutting-edge technology that makes every product strong and reliable. With modern machines and skilled technicians, we ensure consistent quality.

• Customer-Centric Approach: We understand that every client's needs are different, so we provide tailored solutions and friendly support with your satisfaction as a priority.

• Competitive Pricing: High-quality wires are available at an affordable price, giving you the perfect combo of value for money - quality as well as budget.

• Timely Delivery: We understand the value of time. We always work with the commitment of on-time delivery so that your project deadlines are not missed.

• Experienced Team: Our team members have years of technical experience who design and manufacture each product with perfection.
